RFID Fixed Reader 860 960Mhz RS232 RS485 Long Range UHF RFID Reader

Wholesale RFID Fixed Reader 860 960Mhz RS232 RS485 Long Range UHF RFID Reader



1 . Descriptions:



The RFID Fixed Reader 860-960MHz RS232 RS485 Long Range UHF RFID Reader is a type of RFID reader that operates in the ultra-high frequency (UHF) range of 860 to 960 MHz. It is designed to be fixed in a specific location, such as a warehouse or distribution center, and is capable of reading UHF RFID tags at long distances.

The RS232 and RS485 refer to the communication interfaces supported by the reader. RS232 is a serial communication standard, while RS485 is a balanced differential interface commonly used in industrial applications. These interfaces allow the reader to connect to other devices, such as a computer or a control system.

The reader can be utilized in various applications, including inventory management, asset tracking, access control, and supply chain management.



2 . Specifications:



Name	Wholesale RFID Fixed Reader 860 960Mhz RS232 RS485 Long Range UHF RFID Reader
Material	Sheet Metal
Feature	1.RF output power: 1~32dBm(adjustable) 2.Antenna interface: 18 SMA RF interfaces (50Ω) 3.Has fast anti-collision processing algorithm 4.Communication interface: RS232, RS485, USB, Ethernet 5.Power supply: 12V DC/5A or more 6.System error indicator light 7.Comes with over-temperature protection, over-current protection, and short-circuit protection functions 8.Equipped with RFID module offline, Ethernet MAC address failure, and Ethernet physical chip communication failure detection functions 9.Supports two working modes, host control mode and scanning mode 10.Support frequency hopping and fixed frequency working modes 11.Inventory supports buffer mode, which can buffer up to 400 EPC. 12.Supports serial port, USB port, and network port to update firmware online 13.The product has powerful functions, more scalability, and can meet more customer needs.
Weight	800g
Dimensions	308*229*34.5mm
Standard	ISO18000-6C/EPCglobal Gen2
MOQ	1 Piece
Packaging	According to your requirements,polybags,vacuum packing
Payment term	T/T, Western Union, Paypal



3 .Quality Control:



As a professional and practised manufacturing company, we have buit up a series of workable and effective quality control system. Below are two major quality control inspection:



Incoming Quality Control Inspection



1. Purpose:

Checking all incoming material including sub-contractor provide products to ensure the quality meet requirement and nonconformity is found in time so as to prevent released nonconforming incoming material.



2. Scope:

Incoming materials (Expect some material for mold making and ship-to-stock material), including customer-

supplied material and sub-contactor supplied products



3. Definition: N/A

3.1 RMT: RMT is the short form of Reiving Move Ticket.

3.2 MRB: MRB Store means the rejected area assigned by store.



4. Responsibility:

4.1 IQC is responsible for the inspection and test of all in-coming material and parts.

4.2 Purchasing is responsible for informing non-conforming material to vendors / sub-contractors.



5. IQC Flow Chart

Finished Products Inspection:



4 . Applications:



It can be widely used in libraries, file management, production process automation, laundry factory automation management, drug tracking and other fields.

5 . More pictures:



Support and Services:

Technical Support:

1. Free SDK, communicaiton protocols and R-Tool (testing & configuration software) provided.

2. Professional hardware and software engineers to give online or offline support.

Pre-sales Service:

As we have rich experien of many RFID projects after ten years development , especially in RFID library management, RFID personnel management (time and attendan management), RFID jewelry management, RFID casino management, RFID fast food shop management, production line automation, etc., we are able to give recommendation of the most suitable hardware solution in professional advis.

After-sales Service:

As the industry leader in the China RFID industry, we have to prove that we are committed to the confiden of our products. Free warranty is three year for all of our RFID reader and antenna excluding human factor damage.

FAQ:
