HF ISO 15693 13.56MHz RFID Reader Long Reading Distance With RS232 / RS485 Interface

HF ISO 15693 13.56MHz RFID Reader Long Reading Distance With RS232 / RS485 Interface
HF ISO 15693 13.56MHz RFID Reader Long Reading Distance With RS232 / RS485 Interface

Large Image :  HF ISO 15693 13.56MHz RFID Reader Long Reading Distance With RS232 / RS485 Interface

Product Details:
Place of Origin: CHINA
Brand Name: Andea Electronics
Model Number: RD2104
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Packaging Details: Standard Export Carton, Foam and Protective Film
Delivery Time: 3~5 work days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 500~1000 Sets Per Month
Detailed Product Description
RF Power: 0.25~1.5W (adjustable) Antenna Interface: SMA*4
Reading Speed: 70pcs/sec Communication Interface: RS232, RS485, Ethernet, USB
Power Supply: 12V DC Compatiable Protocol: ISO/IEC 15693 And ISO/IEC 18000-3M1
Operating Frequency: 13.56 MHz Working Mode: Host Mode And Auto Read Mode(configurable)
Maximum Power Consumption: 10W Shell Material: Aluminum Alloy
High Light:

13.56MHz RFID Reader

,

ISO 15693 RFID Reader

,

RS485 Interface RFID Reader

HF ISO 15693 13.56MHz RFID Reader Long Reading Distance with RS232/RS485 Interface



Product Introduction:



RD2104 HF medium power RFID reader has high sensitivity and fast anti-collision algorithm, which operates at a frequency of 13.56 MHz and are designed to suit any business application and has wide choices depending upon the user’s specification and needs. Anti-collision algorithm allows fast processing, reading speed is up to 70 pieces per second.



Product Features:



  • Support ISO 15693 and ISO 18000-3M1 standard.
  • RF power: 0.25~1.5W (adjustable).
  • Antenna interface: SMA*4
  • Fast anti-collision processing algorithm; the speed of reading the tag is up to 70pcs / sec.
  • Reading and writing range: single antenna can reach 75cm (antenna size: 560*650mm); (this distance is related to card performance and antenna size).
  • Communication interface: RS232, RS485, Ethernet, USB.
  • Support noise detection, can detect the environment whether there is interference.
  • Power supply: 12V DC.
  • It has multiple working modes which can be configured through software tools.
  • With short circuit protection and overheat protection function.



Parameter/Model RD2101 RD2104/RD2104-F11
Operating Frequency 13.56 MHz
Support Standard ISO/IEC 15693 and ISO/IEC 18000-3M1
RF Power 0.25~1.5W(configurable, the system default setting is1.5W)
Antenna Interface SMA×1 SMA×4
Communication Interface RS232 /RS485/USB/ Ethernet
Working Mode host mode and auto read mode(configurable)
Supply Voltage 12VDC
Maximum Power Consumption 10W
Shell Material aluminum alloy
Dimensions 123×105×25mm
Maximum Operating Temperature 40℃


HF ISO 15693 13.56MHz RFID Reader Long Reading Distance With RS232 / RS485 Interface 0

HF ISO 15693 13.56MHz RFID Reader Long Reading Distance With RS232 / RS485 Interface 1
Product Application:



Some common applications of high frequency 13.56 MHz readers are asset tracking, document management, jewelry inventory, medicine tracking, laundry management, logistic system, express parcel management, production authentication, access control/time recorder, ticketing smart label printer and encoder, system login/logoff, smart checkout multi tag solution, books and video rentals, guest registration system, authorization identification, identity authentication, data collection system, time attendance system, registration system, access control, parking systems, prepaid parking, ticketing, admission control, POS or library management, inventory, warehouse management, drug management and anti-­ counterfeiting, customer benefit programs, and general smart card management systems.
